Top Dead Center – Is When The Piston, Is At The Top Of Its Stroke

Top Dead Center - (TDC) Is When The Piston, Is At The Top Of Its Stroke
Top Dead Center - (TDC) Is When The Piston, Is At The Top Of Its Stroke

Top Dead Center (TDC) refers to, the point when the piston is at the absolute top, of its stroke.

So, a piston can be at Top Dead Center (TDC), on the compression stroke or on the exhaust stroke.

As a general reference point, or when installing a distributor, (TDC) on the compression stroke is required.

So, Top Dead Center (TDC), can usually be found, by looking at timing marks. But, on some engines, these marks may be lost or hidden. Fortunately, there’s an easy way to discover Top Dead Center (TDC), without the use of any timing marks.

Above all, being able to accurately find Top Dead Center (TDC) is a critical step, when working on any engine. Consequently, there are actually many ways to do it. But, in this article we wanted to show you a simple, quick and practically foolproof method for finding it.

Like, when your, building an engine or want to make sure, the timing marks on your damper are correct.

So, if you’re relatively new to engine work and have never, pulled the distributor or damper from your engine. Then, finding Top Dead Center (TDC) on piston #1, becomes an instant priority. Finding Top Dead Center (TDC), is an essential skill, for assembling and tuning engines. And, is even a necessity for performing some engine diagnostic tests, such as a cylinder leak down test.

What Is Top Dead Center (TDC)

Top Dead Centre (TDC)
Top Dead Centre (TDC)

Consequently, Top Dead Centre (TDC) is the position of an engine’s piston, when it is at the very top of its stroke.

Depending on whether you need to be on the compression stroke or not, there are many methods:

  • Compression tester
  • Your Finger
  • Piston Stop Tool
  • Plastic straw
  • TDC whistle
  • Vacuum Pressure Gauge
  • A balloon
  • Timing marks
  • Fingers from a latex glove
  • Coat hanger
  • Welding rod

STEP ONE: Finding Top Dead Center (TDC).

So, the first thing you would want to do is, remove all the spark plugs. Consequently, the reason for this is, you are going to be turning the engine over by hand. Well, most likely with a wrench, on the Harmonic Balancer nut. This will make it a lot easier to turn.


I like to use the hose from my compression tester gauge. ( Make sure to remove the schrader valve from the hose, before you start ). Start, by screwing the hose into the number one cylinder.

Compression Tester Hose
Compression Tester Hose

To determine the location of the, number one cylinder:
On a V type engine, one cylinder head is slightly forward of the other, toward the front of the engine. Cylinder number one is the forward most cylinder in that bank.
On an inline engine, the number one cylinder is located at the front of the engine. Closest to the timing cover.


At this point, there are a few ways to confirm the compression stroke:

Finger on Hose
Finger on Hose

Most old school mechanics would just, use the finger method. Place one finger over over the end of the hose, then rotate the crankshaft. During transition between exhaust and intake strokes, when one or both valves are open. Consequently, there will be no pressure.

During approach to Top Dead Center (TDC), between compression and power strokes, there will be pressure. Consequently, it will push your thumb off of the hose, to allow air to escape. When air stops blowing out, it is fairly near Top Dead Centre (TDC) on the compression stroke. Move on to STEP FOUR.

Vacuum Pressure Gauge
Vacuum Pressure Gauge

Use a vacuum/pressure gauge. Hook up the gauge to your hose. Again turn the engine over by hand until you see pressure. Keep going until you see the pressure change to vacuum. Move on to STEP FOUR.

Use a compression tester. Again turn the engine over by hand, until you see pressure starting to build ( it won’t be much ).  Move on to STEP FOUR.


Other things I have seen are, putting a balloon or a finger from a latex glove over the hose. The balloon or finger will fill up, till it gets to Top Dead Centre (TDC). Then, it will suck back in.

At that point rock back and forth a little, till your zeroed in between suck and blow. And, there you have it, Top Dead Center (TDC) on the compression stroke. Move on to STEP FOUR.


Now, remove the hose and place a long screwdriver, coat hanger or straw into the spark plug hole. Next, feel for the height of the piston.

Turn the crankshaft back and forth (by hand ). Next, observe the motion of the ( screwdriver, coat hanger or straw ). This way you will get a better idea, of the location of the piston. When you see it has reached its highest point of travel, it is at Top Dead Center (TDC). It’s that easy !

Now there are times where you have to be dead on, but this covers most cases.

Top Dead Center (TDC)
Piston Stop Gauge

A more accurate way to locate (TDC) is by using a Piston Stop Tool. Screw the tool into the number one spark plug hole by hand. Next, slowly rotate the crankshaft by hand, until the piston comes up against the stop.

Mark your Harmonic Balancer with a marker, and then slowly rotate the crankshaft by hand, in the opposite direction. Continue, until you come up against the stop again. Mark your Harmonic Balancer again. Measure the distance between the two marks, and divide by two. As a result, this is your Top Dead Centre (TDC).


All things considered, setting an engine to Top Dead Center (TDC), is a relatively simple procedure.
